Atomos Ninja TX GO

Uhlopříčka obrazovky (cm): 13,2
Úhlopříčka obrazovky (palce "): 5,2
Rozlišení: 1920 x 1080
Jasnost (cd/m2): 1500
Poměr stran: 16:9
zásobování energií: přes USB / akumulátor / síťové napájení
Typ aku: Lithium-Ionen
Počet potřebných baterií: 1
Včetně baterií: 1
Typ paměti: CFexpress Typ B
HDMI-Vstup: 1x
HDMI-Výstup: 1x
Připojení sluchátek: ano
LANC: ano
USB: 1x USB-C 2.0 / 1x USB-C 3.0
Typ: Monitor-Recordér
Barva: černá
Šířka (mm): 151
Výška (mm): 36
Hloubka (mm): 92
Hmotnost (g): 400

Ninja TX GO Monitor-Recorder

With the Ninja TX GO you work with a compact 5.2-inch monitor recorder. It has 1500 nits brightness and a Full HD resolution of 1920 x 1080 for a clear image. The case is made of aluminium and ABS, weighs 400 grams, and stays cool with an active fan. Through HDMI you can record signals up to 6Kp30 and use high-quality formats like ProRes RAW or H.265 directly in your workflow.

Powerful image feedback
The display covers Rec.709 and supports log gammas like SLog3, C-Log3 and V-Log. This helps you check exposure and colour. With tools such as waveform, RGB parade and false colour you control your image data directly on the device. It works with HDMI, USB-C or WiFi 6E and processes 8-bit or 10-bit signals in 4:2:2.

Recording and workflow on set
The recorder works with CFexpress Type B or USB media and uses the ExFAT file system for longer clips. For fast delivery you can send recordings directly through ATOMOSphere, Frame.io or Dropbox. With USB-C you can control supported cameras and set start/stop, ISO, aperture or white balance directly from the monitor.

Features:


1500 nits brightness for clear viewing in strong light
6Kp30 over HDMI for high-quality image signals
400 grams weight for easy rigging
Active cooling keeps the recorder stable up to 40 degrees
Colour display with Rec.709 and many log profiles for consistent image control
Waveform, false colour and vectorscope for safe exposure checking
ProRes RAW, ProRes, DNx and H.265 for structured post-production
USB-C camera control for direct adjustment of key settings
Direct cloud upload for fast delivery on set
