Display
- Brightness (ANSI lumens): 3500
- Native Resolution: 1080P (1920x1080)
- Native Aspect Ratio: 16:9
- Contrast Ratio (FOFO): 10,000:1
- Display Color: 30-bit (1.07 billion colors)
- Light Source: Lamp
- Light Source Life: a. Normal 5000 hrs, b. ECO 8000 hrs, c. SmartEco 10000 hrs, d. LampSave 12000 hrs
Optical
- Throw Ratio: 0.33
- Zoom Ratio: Fixed
- Lens: F/# = 2.5, f = 5.1 mm
- Projection Offset (Full-Height): 124%
- Keystone Adjustment: 2D, Vertical ± 15 degrees; Horizontal ± 15 degrees
- Picture Modes: 3D, Bright, Infographic, Presentation, sRGB, User 1, User 2, Vivid
Compatibility
- Input Lag: TBD
- Resolution Support: VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking
- Horizontal Frequency: 15K~102KHz
- Vertical Scan Rate: 23~120Hz
I/O Interface
- PC in (D-sub 15pin): (x1), PC in-1 (shared with component video)
- Monitor out (D-sub 15pin): (x1)
- Composite Video in (RCA): (x1)
- HDMI in - (x2), HDMI-1 (2.0a/HDCP2.2), HDMI-2 (2.0a/HDCP2.2)
- USB Type A: (x1), USB Type A-1 (2.0/Power Supply1.5A)
- USB Type B: (x1), USB Type B-1(service)
- USB Type Mini B: (x1), USB Type Mini B-1(PointWrite)
- RS232 in (DB-9pin): (x1)
Audio
- Speaker: (x2), 10W
- Audio in (3.5mm Mini Jack): (x1), 1
- Audio out (3.5mm Mini Jack): (x1), 1
Environment
- Operating Temperature: 0~40?
- Power Supply: AC 100 to 240 V, 50/60 Hz
- Typical Power Consumption (110V): 320W
- Stand-by Power Consumption: <0.5W
- Network Stand-by Power Consumption: <2W
- Acoustic Noise (Typ./Eco.)(dB): 34/29
Accessories
- Remote Control w/ Battery: RCS011
- Power Cord (by region): x1 (3.0M)
- VGA(D-sub 15pin) Cable: (Standard), 1 (1.8m)
- 3D Glasses: (Optional), DGD5
- Quick Start Guide: 1 (18L)
- Warranty Card (by region): Yes
- Wall Mount: (Standard), Yes, WM04G4
Dimension & Weight
- Dimensions (WxHxD) (mm): 287.5x 206.9 x 373.3
- Net Weight (kg): 5
Projection System
- Projection System: DLP
