Chieftec CMR-125, instalační rám

CMR-125 - The highly innovative backplane CMR-125 sets a new standard by providing an additional HDD/SSD mounting option using a PCI slot. Compatible with all 2,5" HDDs/SSDs (height: 7 ~ 9,5mm) it sources its power via the SATA connection and offers LEDs to indicate HDD access and power while trays are detachable for easy installation. The case being 100% metal and lockable with 2 keys ensures maximum security. All installed discs are hot-swappable which makes it suitable for diverse applications.
Features:

Professional Data Backup
Hot Swap
Plug & Play compatible
Lock mechanism for easy removal of storage media
Key Lock





Interface (HDD/SSD):


SATA I, SATA II, SATA III




Dimension (DxWxH):


138mm x 79mm x 11mm




Weight:


0,12 kg




Form Factor:


1x PCI Slot bay for 1x 2,5" HDDs/SDDs (max. HDD/SSD height up to 9,5mm)




Cooling:


N/A




Power Connector:


1x SATA




Data Interface (ext.):


1 x SATA




Material:


Full Metal structure




Special Features:


HDD LEDs




Scope of delivery:


SATA Backplane, 1x SATA cables, 2 keys, set of screws, User manual
