Aruba 6100 24G Class4 PoE 4SFP+ 370W Switch JL677AR RENEW
Řada přepínačů Aruba CX 6100 je moderní rodina přístupových přepínačů základní úrovně ideální pro pobočky, střední podniky a sítě SMB. Přepínače Aruba CX 6100, navržené pro spolehlivý, jednoduchý a bezpečný přístup, poskytují pohodlné řešení kabelového přístupu pro podnikové sítě podporující IoT, mobilní a cloudové aplikace.
Technické parametry
24x 10/100/1000Base-T porty
4x 1/10G SFP porty
1x USB-C Console Port, 1x USB Type-A Host port
Interní (pevný) napájecí zdroj (500 W), pevné ventilátory
Maximální výkon: 32,7 W bez PoE, 455 W s PoE
Vstupní napětí: 100-127 VAC / 200-240 VAC
Přepínací kapacita: 128 Gb/s
Propustnost: 95,2 Mpps
Procesor: Dual Core ARM Cortex A9 @ 1016 Mhz
Paměť a Flash: 4 GB DDR3, 16 GB eMMC
Možnost PoE: Až 370W Class 4 PoE
Rozměry: 4,39 x 44,2 x 26,82 cm
Hmotnost: 4,2 kg
HPE Aruba Networking CX 6100 Switch Specifications
HPE Aruba Networking CX 6100 24G Class4 PoE4SFP+ 370W Switch
Product Number
JL677A
Differentiator
24x 10/100/1000BASE-T Ports 4x 1G/10G SFP+ Ports Supports IEEE 802.3af, 802.3at PoE Standards 1x USB-C Console Port 1x USB Type-A Host Port Fixed Power Supply (370W Class 4 PoE) Fixed Fans
Ports
24x 10/100/1000BASE-T Ports 4x 1G/10G SFP+ Ports
Memory and Processor
Dual Core ARM Cortex A9 @ 1016 MHz 4 GB DDR3 RAM 16 GB eMMC Storage
Latency
1 Gbps: 1.5 µs 10 Gbps: 1.8 µs
Throughput
95.2 Mpps
Switching Capacity
128 Gbps
PoE Capability
370W Class 4 PoE / PoE+
Input Voltage
100–127 VAC / 200–240 VAC
Power Consumption
Max Power (without PoE): 32.7W Max Power (with PoE): 455W
Product Dimensions
4.4 x 44.2 x 26.8 cm
Weight
4.2 kg
Specifications
Aruba 6100 24G Class4 PoE 4SFP+ 370W Switch (JL677A)
Description
24x ports 10/100/1000BASE-T Ports 4x 1G/10G SFP ports Supports PoE Standards IEEE 802.3af, 802.3at 1x USB-C Console Port 1x USB Type-A Host port
Power supplies
Fixed power supply (500W) Up to 370W of Class 4 PoE Power
Fans
Fixed fans
Physical characteristics
Dimensions
(H) 4.39 cm (W) 44.2 cm (D) 26.82 cm (1.73" x 17.4" x 10.56")
Configuration Weight
4.19kg (9.24 lbs)
Additional Specifications
CPU
Dual Core ARM Cortex A9 @ 1016 Mhz
Memory and Flash
4 GB DDR3 16 GB eMMC
Packet Buffer
12.38MB (4.5MB Ingress/7.875MB Egress)
Performance
Model Switching Capacity
128 Gbps
Model Throughput Capacity
95.2 Mpps
Average Latency (LIFO-64- bytes packets)
1 Gbps: 1.5 µSec , 10 Gbps: 1.8 µSec
Switched Virtual Interfaces (dual stack)
16
IPv4 Host Table (ARP)
1,024
IPv6 Host Table (ND)
512
IPv4 Unicast Routes
512
IPv6 Unicast Routes
512
MAC Table Capacity
8,192
IGMP Groups
512
MLD Groups
512
IPv4/IPv6/MAC ACL Entries (ingress)
256 / 128 / 256
Environment
Operating Temperature
32°F to 113°F (0°C to 45°C) up to 5000 ft (1.5 km) derate -1°C for every 1000 ft (305 m) from 5000 ft (1.5 km) to 10000 ft (3.0 km)
Operating Relative Humidity
15% to 95% at 104°F (40°C) non-condensing
Non-Operating
-40°F to 158°F (-40°C to 70°C) up to 15000 ft (4.6 km)
Non-Operating Storage Relative Humidity
15% to 90% @ 149°F (65°C) non-condensing
Max Operating Altitude
10000 feet (3 km) Max
Max Non-Operating Altitude
15000 feet (4.6 km) Max
Acoustic
Sound Power, LWAd = 3.9 Bel Sound Pressure, LpAm (Bystander)= 24.3 dB
Primary Airflow
Side-to-side
Electrical Characteristics
Frequency
50 / 60 Hz
AC Voltage
100-127 VAC / 200-240 VAC
Current
4.6 A / 2.3 A
Power Consumption (230 VAC)
Idle: 22.9W Max Power (w/o PoE): 32.7W Max Power (w/ PoE): 455W
Safety
UL 60950-1; IEC 60950-1;
EN 60950-1; CAN/
CSA-C22.2 No. 60950-1;
EN 60825-1
UL 62368-1 Ed. 2; IEC
62368-1 Ed. 2; EN 62368-1:2014
Emissions
VCCI-CISPR 32, Class A; CNS
13438; ICES-003 Issue 6
Class A; FCC CFR 47
Part 15, Class A;
EN 55032: 2015 +AC:2016 /
CISPR-32, Class A
Aruba 6100 24G Class4 PoE 4SFP+ 370W Switch (JL677A)
Lasers
EN 60825-1:2007 / IEC 60825- 1:2007 Class 1 Class 1 Laser Products / Laser Klasse 1 (Applicable for accessories - Optical Transceivers only)
Immunity
Generic
CISPR 24 / CISPR 35
EN
EN 55024:2010 /
EN 55035:2017
ESD
IEC 61000-4-2
Radiated
IEC 61000-4-3
EFT/Burst
IEC 61000-4-4
Surge
IEC 61000-4-5
Conducted
IEC 61000-4-6
Power frequency magnetic field
IEC 61000-4-8
Voltage dips and interruptions
IEC 61000-4-11
Harmonics
EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3
Mounting and Enclosure
Mounts in an EIA-standard 19-inch telco rack or equipment cabinet (rack-mounting kit available); horizontal surface mounting; wall mounting
HPE Aruba Networking CX 6100 Switch Series
The HPE Aruba Networking CX 6100 Switch Series is a modern family of entry level access switches ideal for enterprise branch offices and SMB networks. Optimized for reliable, simple, and secure access, the HPE Aruba Networking CX 6100 Switch series switches provide a convenient wired access solution for networks supporting IoT, mobile and cloud applications. CX 6100 Switch series is based on the HPE Aruba Networking ASIC architecture with the programmable AOS-CX operating system used across the entire HPE Aruba Networking CX portfolio for a more consistent, more efficient operator experience. This fully managed Layer 2 switch series has convenient built-in high-speed uplinks with up to 370W of PoE to support IoT devices, such as security cameras and wireless APs, and includes a compact and fanless model ideal for use in quiet workspaces. CX 6100 Switch series supports management choices that include Web GUI, CLI, cloud-based and on-premises HPE Aruba Networking Central, so you can choose the best fit for your needs today with flexibility to change without replacing hardware. With enhanced access security, traffic prioritization, and IPv6 support, the HPE Aruba Networking CX 6100 Switch series also simplifies ownership and brings peace of mind with switch software embedded with no subscription required to enable and a Limited Lifetime Warranty.
Key Features
Enterprise-class Layer 2 connectivity with support for ACLs, robust QoS and static routing
Convenient built-in 1/10GbE uplinks and up to 740W of Class 4 PoE for support of IoT devices
Compact and fanless 12 port model for quiet deployment
Manage via single pane of glass with HPE Aruba Networking Central across wired, wireless, and WAN
Automated configuration and verification with HPE Aruba Networking NetEdit
Software defined ready with REST APIs
Simplify adds, moves and changes with colorless ports
Standard Features
Product Differentiators
AOS-CX - A modern software system
The HPE Aruba Networking CX 6100 Switch Series is based on AOS-CX, a modern, database-driven operating system that is built on a modular Linux architecture. This operating system provides the following unique capabilities:
Easy access to all network configuration state information
REST APIs for fine-grained programmability of netw...
