HPE FlexNetwork 5140 8G 2SFP 2GT Combo EI Switch R8J42A RENEW
HPE FlexNetwork 5140 8G 2SFP 2GT Combo EI Switch R8J42A RENEW
18292 Kč
15117 Kč bez DPH
Dostupnost: Skladem v eshopu
Part no.: R8J42AR
Kód produktu: 105200166
Výrobce: Hewlett Packard Enterprise
 |
Potřebujete více informací?
484800850 po-pá 8:00-16:30 |
Popis produktu
Klíčové vlastnosti
Škálovatelnost a vysoká dostupnost
Komplexní řízení zabezpečení
Zjednodušená správa
Zvýšená kvalita služeb
Technické parametry Porty a sloty
(8) RJ-45 autosensing 10/100/1000 ports
(2) SFP fixed 1000/10000 SFP ports
(2) RJ-45 1/10GBASE-T ports
Spotřeba
15 W (maximum)
Rozměry
4.36 x 10.47 x 16 cm
Hmotnost
1.5 kg
Odkaz na stránku výrobce: https://buy.hpe.com/fi/en/networking/switches/fixed-port-l3-managed-ethernet-switches/5100-switch-products/hpe-flexnetwork-5140-ei-switch-series/hpe-flexnetwork-5140-8g-2sfp-2gt-combo-ei-switch/p/R8J42A
Environment
Operating temperature
23°F to 113°F (-5°C to 45°C)
Operating relative humidity
10% to 90%, noncondensing
Non-operating/Storage temperature
-40°F to 158°F (-40°C to 70°C)
Non-operating/Storage relative humidity
5% to 95%, noncondensing
Acoustic
Low-speed fan: 43.5 dB, High-speed fan: 52.8 dB; ISO 7779
Electrical characteristics
Frequency
50/60 Hz
Maximum heat dissipation
160/1671 BTU/hr (168.8/1762.91 kJ/hr), for AC power. For DC power min heat dissipation is 147 BTU/hr and 3037 BTU/hr max.
Voltage
100 - 240 VAC
-54 to -57 VDC
Current
10 A
Maximum power rating
478 W
Idle power
47 W
PoE power
370 W PoE+
Notes:
- Idle power is the actual power consumption of the device with no ports connected. Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated. PoE Power is the power supplied by the internal power supply. When supplemented with the use of an HPE RPS1600 Redundant Power System, up to 740 W of PoE+ can be supplied.
- Max current rating for DC power is 25A. AC Input power is 47W typical, and 490W max(including 370W PoE+ consumption. DC Input voltage range is -54 to -57VDC. Total DC input power is 43W typical and 890W with 800W PoE+ Power consumption. DC Input voltage range is -54VDC to -57VDC. DC Input Source is the HPE RPS1600.
Safety
UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2; IEC 60950-1; IEC 62368-1; CAN/CSA-C22.2 No. 60950-1; EN 62368-1/A11; FDA 21 CFR Subchapter J; ROHS Compliance
Emissions
FCC Part 15 Subpart B CLASS A; ICES-003 CLASS A; VCCI-CISPR 32 CLASS A; EN 55032 CLASS; AS/NZS CISPR32 CLASS A; CISPR 24; EN 55024; EN 61000-3-2; EN 61000-3-3; ETSI EN 300 386; GB/T 9254; YD/T 993
Immunity
Generic
EN 55024
ESD
EN300 386
Management
IMC - Intelligent Management Center; SmartMC; command-line interface; Web browser; SNMP Manager
Services
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for details on the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local Hewlett Packard Enterprise sales office.
HPE FlexNetwork 5140 24G PoE+ 2SFP+ 2XGT (370W) EI Switch (JL823A )
I/O ports and slots
24 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: Ports 1-24 support 10BASE-T/100BASE-TX, 1000BASE-T (full only)
2 SFP+ fixed 1000/10000 SFP+ ports
2X1/2.5/5/10G BASE-T ports
Additional ports and slots
1 RJ-45 serial console port
Physical characteristics
Dimensions
17.32(w) x 12.6(d) x 1.72(h) in (44 x 32 x 4.36 cm) (1U height)
Weight
9.92 lb (4.5 kg)
Memory and processor
512 MB SDRAM, 256 MB flash
Mounting and enclosure
Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware included)
Performance
IPv6 Ready Certified
1000 Mb Latency
< 5 µs
10 Gbps Latency
< 3 µs
Throughput
95 Mpps
Routing/Switching capacity
128 Gbps
Routing table size
512 entries (IPv4), 256 entries (IPv6)
MAC address table size
16384 entries
Environment
Operating temperature
23°F to 122°F (-5°C to 50°C)
Operating relative humidity
10% to 90%, noncondensing
Non-operating/Storage temperature
-40°F to 158°F (-40°C to 70°C)
Non-operating/Storage relative humidity
5% to 95%, noncondensing
Acoustic
Low-speed fan: 44.4 dB, High-speed fan: 52.8 dB; ISO 7779
Electrical characteristics
Frequency
50/60 Hz
Maximum heat dissipation
83.6/1433 BTU/hr (88.2/1511.9 kJ/hr)
Voltage
100 - 240 VAC
Current
10 A
Maximum power rating
420 W
Idle power
24.5 W
PoE power
370 W PoE+
Notes:
Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated. PoE Power is the power supplied by the internal power supply. When supplemented with the use of an HPE RPS1600 Redundant Power System, up to 740 W of PoE+ can be supplied.
Safety
UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2; IEC 60950-1; IEC 62368-1; CAN/CSA-C22.2 No. 60950-1; EN 62368-1/A11; FDA 21 CFR Subchapter J; ROHS Compliance
Emissions
FCC Part 15 Subpart CLASS A; ICES-003 CLASS A; VCCI-CISPR 32 CLASS A; EN 55032 CLASS; AS/NZS CISPR32 CLASS A; CISPR 24; EN 55024; EN 61000-3-2; EN 61000-3-3; ETSI EN 300 386; GB/T 9254; YD/T 993
Immunity
Generic
EN 55024
ESD
EN300 386
Management
IMC - Intelligent Management Center; SmartMC; command-line interface; Web browser; SNMP Manager.
Services
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for details on the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local Hewlett Packard Enterprise sales office.
HPE FlexNetwork 5140 48G PoE+ 2SFP+ 2XGT (370W) EI Switch (JL825A )
I/O ports and slots
48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
2 SFP+ fixed 1000/10000 SFP+ ports
2X1/2.5/5/10G BASE-T ports
Additional ports and slots
1 RJ-45 serial console port
Physical characteristics
Dimensions
17.32(w) x 12.6(d) x 1.72(h) in (44 x 32 x 4.36 cm) (1U height)
Weight
13.23 lb (6 kg)
Memory and processor
512 MB SDRAM, 256 MB flash
...
Popis produktu
Gigabitový ethernetový přístupový přepínač se statickým směrováním na 3. vrstvě, RIP, vysokou hustotou 10GbE uplinků a modely POE+ pro hlas, video a bezdrátové připojení. Podporuje technologii IRF, která umožňuje agregaci zařízení plug-and-play a agregaci linek mezi více zařízeními, čímž zvyšuje redundanci sítě a využití zdrojů. Obsahuje vestavěné funkce pro správu sítě pomocí Smart Management Center (SmartMC). Zahrnuje energeticky úsporné ekologické konstrukční funkce, jako je automatické přepínání nečinných portů do energeticky úsporného režimu a vypínání nepoužívaných portů.Klíčové vlastnosti
Škálovatelnost a vysoká dostupnost
Komplexní řízení zabezpečení
Zjednodušená správa
Zvýšená kvalita služeb
Technické parametry Porty a sloty
(8) RJ-45 autosensing 10/100/1000 ports
(2) SFP fixed 1000/10000 SFP ports
(2) RJ-45 1/10GBASE-T ports
Spotřeba
15 W (maximum)
Rozměry
4.36 x 10.47 x 16 cm
Hmotnost
1.5 kg
Odkaz na stránku výrobce: https://buy.hpe.com/fi/en/networking/switches/fixed-port-l3-managed-ethernet-switches/5100-switch-products/hpe-flexnetwork-5140-ei-switch-series/hpe-flexnetwork-5140-8g-2sfp-2gt-combo-ei-switch/p/R8J42A
Environment
Operating temperature
23°F to 113°F (-5°C to 45°C)
Operating relative humidity
10% to 90%, noncondensing
Non-operating/Storage temperature
-40°F to 158°F (-40°C to 70°C)
Non-operating/Storage relative humidity
5% to 95%, noncondensing
Acoustic
Low-speed fan: 43.5 dB, High-speed fan: 52.8 dB; ISO 7779
Electrical characteristics
Frequency
50/60 Hz
Maximum heat dissipation
160/1671 BTU/hr (168.8/1762.91 kJ/hr), for AC power. For DC power min heat dissipation is 147 BTU/hr and 3037 BTU/hr max.
Voltage
100 - 240 VAC
-54 to -57 VDC
Current
10 A
Maximum power rating
478 W
Idle power
47 W
PoE power
370 W PoE+
Notes:
- Idle power is the actual power consumption of the device with no ports connected. Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated. PoE Power is the power supplied by the internal power supply. When supplemented with the use of an HPE RPS1600 Redundant Power System, up to 740 W of PoE+ can be supplied.
- Max current rating for DC power is 25A. AC Input power is 47W typical, and 490W max(including 370W PoE+ consumption. DC Input voltage range is -54 to -57VDC. Total DC input power is 43W typical and 890W with 800W PoE+ Power consumption. DC Input voltage range is -54VDC to -57VDC. DC Input Source is the HPE RPS1600.
Safety
UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2; IEC 60950-1; IEC 62368-1; CAN/CSA-C22.2 No. 60950-1; EN 62368-1/A11; FDA 21 CFR Subchapter J; ROHS Compliance
Emissions
FCC Part 15 Subpart B CLASS A; ICES-003 CLASS A; VCCI-CISPR 32 CLASS A; EN 55032 CLASS; AS/NZS CISPR32 CLASS A; CISPR 24; EN 55024; EN 61000-3-2; EN 61000-3-3; ETSI EN 300 386; GB/T 9254; YD/T 993
Immunity
Generic
EN 55024
ESD
EN300 386
Management
IMC - Intelligent Management Center; SmartMC; command-line interface; Web browser; SNMP Manager
Services
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for details on the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local Hewlett Packard Enterprise sales office.
HPE FlexNetwork 5140 24G PoE+ 2SFP+ 2XGT (370W) EI Switch (JL823A )
I/O ports and slots
24 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: Ports 1-24 support 10BASE-T/100BASE-TX, 1000BASE-T (full only)
2 SFP+ fixed 1000/10000 SFP+ ports
2X1/2.5/5/10G BASE-T ports
Additional ports and slots
1 RJ-45 serial console port
Physical characteristics
Dimensions
17.32(w) x 12.6(d) x 1.72(h) in (44 x 32 x 4.36 cm) (1U height)
Weight
9.92 lb (4.5 kg)
Memory and processor
512 MB SDRAM, 256 MB flash
Mounting and enclosure
Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware included)
Performance
IPv6 Ready Certified
1000 Mb Latency
< 5 µs
10 Gbps Latency
< 3 µs
Throughput
95 Mpps
Routing/Switching capacity
128 Gbps
Routing table size
512 entries (IPv4), 256 entries (IPv6)
MAC address table size
16384 entries
Environment
Operating temperature
23°F to 122°F (-5°C to 50°C)
Operating relative humidity
10% to 90%, noncondensing
Non-operating/Storage temperature
-40°F to 158°F (-40°C to 70°C)
Non-operating/Storage relative humidity
5% to 95%, noncondensing
Acoustic
Low-speed fan: 44.4 dB, High-speed fan: 52.8 dB; ISO 7779
Electrical characteristics
Frequency
50/60 Hz
Maximum heat dissipation
83.6/1433 BTU/hr (88.2/1511.9 kJ/hr)
Voltage
100 - 240 VAC
Current
10 A
Maximum power rating
420 W
Idle power
24.5 W
PoE power
370 W PoE+
Notes:
Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated. PoE Power is the power supplied by the internal power supply. When supplemented with the use of an HPE RPS1600 Redundant Power System, up to 740 W of PoE+ can be supplied.
Safety
UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2; IEC 60950-1; IEC 62368-1; CAN/CSA-C22.2 No. 60950-1; EN 62368-1/A11; FDA 21 CFR Subchapter J; ROHS Compliance
Emissions
FCC Part 15 Subpart CLASS A; ICES-003 CLASS A; VCCI-CISPR 32 CLASS A; EN 55032 CLASS; AS/NZS CISPR32 CLASS A; CISPR 24; EN 55024; EN 61000-3-2; EN 61000-3-3; ETSI EN 300 386; GB/T 9254; YD/T 993
Immunity
Generic
EN 55024
ESD
EN300 386
Management
IMC - Intelligent Management Center; SmartMC; command-line interface; Web browser; SNMP Manager.
Services
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for details on the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local Hewlett Packard Enterprise sales office.
HPE FlexNetwork 5140 48G PoE+ 2SFP+ 2XGT (370W) EI Switch (JL825A )
I/O ports and slots
48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
2 SFP+ fixed 1000/10000 SFP+ ports
2X1/2.5/5/10G BASE-T ports
Additional ports and slots
1 RJ-45 serial console port
Physical characteristics
Dimensions
17.32(w) x 12.6(d) x 1.72(h) in (44 x 32 x 4.36 cm) (1U height)
Weight
13.23 lb (6 kg)
Memory and processor
512 MB SDRAM, 256 MB flash
...
