INTEL 4-core Xeon E-2274G 4GHZ/8MB/FCLGA1151/83W

Essentials
Product Collection Intel® Xeon® E Processor
Code Name Products formerly Coffee Lake
Vertical Segment Server
Processor Number E-2274G
Lithography 14 nm

Performance
# of Cores 4
# of Threads 8
Processor Base Frequency 4.00 GHz
Max Turbo Frequency 4.90 GHz
Cache 8 MB Intel® Smart Cache
TDP 83 W

Memory Specifications
Max Memory Size (dependent on memory type) 128 GB
Memory Types DDR4-2666
Max # of Memory Channels 2
ECC Memory Supported ‡ Yes
Processor Graphics
Processor Graphics ‡ Intel® UHD Graphics P630
Graphics Base Frequency 350 MHz
Graphics Max Dynamic Frequency 1.20 GHz
Graphics Video Max Memory 128 GB
4K Support Yes, at 60Hz
Max Resolution (HDMI 1.4)‡ 4096x2160@24Hz
Max Resolution (DP)‡ 4096x2304@60Hz
Max Resolution (eDP - Integrated Flat Panel)‡ 4096x2304@60Hz
Max Resolution (VGA)‡ N/A
DirectX* Support 12
OpenGL* Support 4.5
Intel® Quick Sync Video Yes
Intel® InTru™ 3D Technology Yes
Intel® Clear Video HD Technology Yes
Intel® Clea
# of Displays Supported ‡ 3
Device ID 0x3E96

Expansion Options
Scalability 1S Only
PCI Express Revision 3.0
PCI Express Configurations ‡ 1x16,2x8,1x8+2x4
Max # of PCI Express Lanes 16

Package Specifications
Sockets Supported FCLGA1151
Max CPU Configuration 1
TCASE 69.3°C
TJUNCTION 100
Package Size 37.5 mm x 37.5 mm

Advanced Technologies
Intel® Optane™ Memory Supported ‡ Yes
Intel® Turbo Boost Technology ‡ 2.0
Intel® vPro™ Platform Eligibility ‡ Yes
Intel® Hyper-Threading Technology ‡ Yes
Intel® Virtualization Technology (VT-x) ‡ Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
Intel® TSX-NI Yes
Intel® 64 ‡ Yes
Instruction Set 64-bit
Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Thermal Monitoring Technologies Yes

Security & Reliability
Intel® AES New Instructions Yes
Secure Key Yes
Intel® Software Guard Extensions (Intel® SGX) Yes with both Intel® SPS and Intel® ME
Intel® Memory Protection Extensions (Intel® MPX) Yes
Intel® OS Guard Yes
Intel® Trusted Execution Technology ‡ Yes
Execute Disable Bit ‡ Yes
Intel® Boot Guard Yes
