LC-Power LC1000P V3.0

Zkrat (SCP): ano
Proudové špičky (OCP): ano
Přetížení (OVP): ano
Podpětí (UVP): ano
Přehřátí (OTP): ano
Přetížení (OPP): ano
Ventilátor (počet): 1
Způsob chlazení: aktivní
Průměr větráku (mm): 135
Typ PFC (Power Factor Correction): Aktiv-PFC
ATX-Mainboard: 1x 20+4pin
ATX12V: 2x 4+4pin
PCIe: 6x 6+2pin
PCIe 5.0 (12VHPWR): 1x 600W
S-ATA: 10x
P-ATA / IDE: 5x
Výkon (Watt): 1000
Form faktor: ATX
Verze ATX: 3.0
certifikace: 80PLUS Platinum
Účinnost při plné zátěži (%): 92
Barva: černá
Šířka (mm): 180
Výška (mm): 86
Hloubka (mm): 150

LC Power LC1000P V3.0 PC Power Supply

The fully modular LC1000P V3.0 power supply is 80 PLUS PLATINUM certified and provides very high stability even at full performance.
Thanks to the fully modular cable management, it offers a very high level of comfort when building or upgrading your systems. The power supply also impresses with an efficiency of up to 92 percent.

Features:


ATX form factor 3.0
Power: 1000 W
Fan size: 135 mm fan
Fully modular cable management
Black cable with cable
80 PLUS PLATINUM certified
High efficiency up to 92%
Full range: 110 - 240 V
DC-to-DC technology
Powerful +12 V line (83.3 A)
Connections:

1x 20+4-pin mainboard (1x 650 mm)
2x 4+4-pin mainboard 12V / 8-pin EPS (2x 650 mm)
1x PCI-Express 5.0 12+4-pin (1x 600 mm for a graphics card up to 600 W)
6 x PCI-Express 6+2-pin (3x 675 mm, 3x 750 mm)
10x SATA (3x 500 mm, 3x 650 mm, 2x 800 mm, 2x 950 mm)
5x PATA (1x 350 mm, 2x 500 mm, 1x 650 mm, 1x 800 mm)


Safety circuits: OVP = overvoltage protection, OCP = overcurrent protection, OPP = overpower protection, OTP = overheat protection, SCP = short-circuit protection, UVP = undervoltage protection
Power supply dimensions: 86 x 180 x 150 mm
Colour: black
