PERFORMANCE Processor Intel® Core Ultra 5 225, 10C (6P + 4E) / 10T, Max Turbo up to 4.9GHz, 20MB Intel Smart Cache AI PC Category AI PC Graphics Integrated Intel® Graphics Chipset Intel® B860 Chipset Memory 1x 16GB UDIMM DDR5-5600 Memory Slots Two DDR5 UDIMM slots, dual-channel capable Max Memory Up to 64GB DDR5-5600 Storage 512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0 Max Storage Support Up to three drives, 1x 3.5" HDD + 2x M.2 SSD
• 3.5" HDD up to 2TB
• M.2 SSD up to 1TB each For installing HDD storage, 3.5 HDD screw and grommet kit is needed. Card Reader 3-in-1 Card Reader Optical 9.0mm DVD±RW Audio Chip High Definition (HD) Audio, Realtek® ALC623-CG codec 24-bit DAC supports 44.1K/48K/96K sample rate, 2 channel DAC supports 16/20/24-bit PCM format for independent two stereo channel or 2.1 audio playback 24-bit ADC supports 44.1K/48K/96K sample rate, 2 channel ADC supports 16/20/24-bit PCM format for independent two stereo channel audio inputs Speakers 1Wx1 Power Supply 200W 90% DESIGN Keyboard USB, Calliope, Black, Czech / Slovakian Mouse USB Calliope Mouse, Black Expansion Slots One PCIe® 4.0 x16, low-profile, length ? 155mm, height ? 70mm One PCIe® 3.0 x1, low-profile, length ? 155mm, height ? 70mm Three M.2 slots (one for WLAN, two for SSD) Case Color Raven Black Stand None Pen Pen Not Supported Form Factor SFF (8.2L) Dimensions (WxDxH) 92.5 x 291.7 x 339.5 mm (3.6 x 11.5 x 13.4 inches) Weight Around 4.62 kg (10.19 lbs.) CONNECTIVITY WLAN + Bluetooth Intel® Wi-Fi® 6 AX203, 802.11ax 2x2 + BT5.2 WWAN Non-WWAN Ethernet Integrated 100/1000M Front Ports 1x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with 15W charging 2x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x headphone / microphone combo jack (3.5mm) 1x microphone (3.5mm) Rear Ports 2x USB-A (Hi-Speed USB / USB 2.0) 2x USB-A (USB 5Gbps / USB 3.2 Gen 1), one supports Smart Power On 1x HDMI® 2.1 TMDS 1x DisplayPort™ 1.4 1x Ethernet (RJ-45) 1x line-out (3.5mm) Optional Rear Ports (configured) None Monitor Cable None SECURITY & PRIVACY Security Chip Discrete TPM 2.0, TCG certified, FIPS 140-2 certified Physical Locks Kensington® Security Slot™, 3 x 7 mm Padlock Loop Smart Cable Clip None Chassis Intrusion Switch Chassis Intrusion Switch Additional Security None MANAGEABILITY System Management Non-vPro® SERVICE Base Warranty 1-year, Courier or Carry-in Included Upgrade 3Y Onsite upgrade from 1Y Courier/Carry-in (CPN) CERTIFICATIONS Green Certifications ENERGY STAR® 9.0 RoHS / WEEE / REACH Other Certifications - SOFTWARE Operating System Windows® 11 Pro, Czech / Slovak / English Bundled Software None ACCESSORIES Bundled Accessories 3.5" HDD Screw and Grommet Kit MODEL INFORMATION Model 13DM000MCK Machine Type 13DM Region EET Country/Region Czech, Slovakia TopSeller Yes EAN / UPC / JAN 0199272237969 Announce Date 2025-09-09 End of Support 2032-04-09
