PERFORMANCE Processor Intel® Core™ Ultra 7 258V, 8C (4P + 4LPE) / 8T, Max Turbo up to 4.8GHz, 12MB AI PC Category Copilot+ PC NPU Integrated Intel® AI Boost, up to 47 TOPS Graphics Integrated Intel® Arc™ Graphics 140V Chipset Intel® SoC Platform Memory 32GB Soldered LPDDR5x-8533, MoP Memory Memory Slots Memory soldered to systemboard, no slots, dual-channel Max Memory 32GB soldered memory, not upgradable Storage 2TB SSD M.2 2280 PCIe® 5.0x4 Performance NVMe® Opal 2.0 Storage Support One drive, up to 2TB M.2 2280 SSD Storage Slot Models with V or H series processor: one M.2 2280 PCIe® 5.0 x4 slot Card Reader None Audio Chip Models with V series processor: High Definition (HD) Audio, Realtek® ALC713 codec Speakers Stereo speakers, 2W x2, Dolby Atmos® Camera FHD 1080p + IR Discrete with Privacy Shutter Microphone 2x, 360° Battery 57Wh Power Adapter 65W USB-C® Slim GaN (3-pin) DESIGN Display 14" 2.8K (2880x1800) OLED 500nits Anti-glare / Anti-reflection / Anti-smudge, 100% DCI-P3, 120Hz VRR, DisplayHDR™ True Black 500, Dolby Vision® Touchscreen None Keyboard Backlit, Czech / Slovak Touchpad Haptic Touchpad Case Color Black, Paint Case Material Carbon Fiber (Top), Aluminium (Bottom) Pen Pen Not Supported Dimensions (WxDxH) 312.80 x 214.75 x 8.08/14.37 (front/rear), 16.95 (maximum) mm;
12.31 x 8.45 x 0.32/0.56 (front/rear), 0.67 (maximum)inches Weight Starting at 986 g (2.17 lbs) SOFTWARE Operating System Windows® 11 Pro, Czech / Slovak / English Bundled Software Intel® Connectivity Performance Suite + Lenovo® AI Now CONNECTIVITY WLAN + Bluetooth Intel® Wi-Fi® 7 BE201, 802.11be 2x2 + BT5.4 WWAN Quectel RM520N-GL, 5G Sub-6 GHz, with Embedded eSIM SIM Card None Ethernet No Onboard Ethernet NFC None Standard Ports 1x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 2.1 1x HDMI® 2.1, up to 4K/60Hz 1x Headphone / microphone combo jack (3.5mm) Optional Ports (configured) 1x Nano-SIM Card Slot Docking Various docking solutions supported via Thunderbolt™ / USB-C®.
For more compatible docking solutions, please visit Docking for ThinkPad® X1 Carbon Gen 13 SECURITY & PRIVACY Smart Card Reader None Security Chip Discrete TPM 2.0 Enabled Fingerprint Reader Touch Style, Match-on-Chip, in Keyboard Key Physical Locks Kensington® Nano Security Slot™, 2.5 x 6 mm Other Security Camera privacy shutter IR camera for Windows® Hello (facial recognition) MANAGEABILITY System Management Non-vPro® SERVICE Base Warranty 3-year, Courier or Carry-in Included Upgrade 3Y Premier Support WHB (CPN), CO2 Offset 0.5 ton (2nd Generation Carbon Offset Projects) ACCESSORIES Bundled Accessories None CERTIFICATIONS Green Certifications ENERGY STAR® 8.0 EPEAT™ Gold Registered ErP Lot 6/26 RoHS compliant TCO Certified 10.0 Other Certifications Eyesafe® Certified 2.0 Intel® Evo™ Platform SGS High Performance Al PC Certification Mil-Spec Test MIL-STD-810H military test passed MODEL INFORMATION Model 21NS004TCK Country/Region Czech, Slovakia TopSeller Yes EAN / UPC / JAN 0198156499899 Announce Date 2025-02-21 End of Support 2031-06-05
