Metabo CS 22-355 Metal Chop Saw

Max. průměr kotouče (mm): 355
Výkon (Watt): 2300
Napětí (V): 230
Integrované odsávání prachu: ne
Akustický tlak: 91
Typ: Bruska
Způsob provozu: Síť
Barva: zelená / černá
Hmotnost (kg): 16,8

Metabo CS 22-355 Metal cut-off sander, mitre-bound

Powerful metal cut-off grinder with infinitely variable mitre adjustment for cutting profiles, pipes or rods. Mitre adjustment for angle cuts from -15 to 45 degrees.

Features:


Powerful metal cut-off sander
For cutting pipes, rods and profiles made of steel, non-ferrous metals, iron and cast profiles
Quick-clamping device, infinitely variable mitre adjustment for angle cuts from -15° to 45°
Optimum power transmission thanks to large handle across the cutting axis
Adjustable cutting depth limiter
Quick and easy disc change with spindle lock
High level of user protection: swivelling cut-off guard, adjustable spark deflector and rubberised feet
Safety switch prevents unintentional starting
Integrated carrying handle and transport lock for easy transport


Technical data:


For sanding discs (O x bore): 355 x 25.4 mm
Idle speed: 3700 /min
Rated power input: 2300 W
Max. Cutting capacity round tube: 132 mm
Max. Cutting capacity square tube: 120 x 120 mm
Max. Rectangular tube cutting capacity: 100 x 208 mm
Max. Cutting capacity L-profile: 150 x 150 mm
Base plate dimensions: 456 x 256 mm
Transport height: 394 mm
Weight: 16.8 kg
Cable length: 4 m


Scope of delivery:


Metabo CS 22-355 metal cutting-off machine
Hexagon spanner
Support flange
Clamping nut
Cutting disc 355 mm
